Investment casting service- casting turbine
Investment casting of centrifugal pump, turbocharger and multistage pump impellers in stainless steel and copper alloy. High-precision, durable, ideal for various industrial applications, ensuring efficient fluid handling performance.
Investment casting, also known as lost wax casting, is a casting method in which a pattern is made of a melt-able material, then coated with several layers of refractory material to form a shell, and the pattern is melted away after high-temperature firing, and then the molten metal is poured into the shell.
Investment casting have high precision and high surface quality, with small machining allowances, which can achieve less or no machining requires. Investment casting can cast complex thin-walled parts with complex shapes (the minimum wall thickness can reach 0.25-0.4mm), and the smallest hole diameter can reach 2.5mm.
The process normal as below:
Drawing Review ->Tooling Designing ->Tooling Manufacturing ->Wax Pattern Making ->Pattern Tree Assembly ->Dipping and Coating ->De-waxing and Firing- Pouring-Knockout ->Grinding ->Heat Treatment -> Machining(if requires) ->Inspection->Delivery
Leesh holdings is the key leading supplier of investment cast parts to both China market and global market.Through many years development, our casting parts now services in railway, automobile and truck, construction machinery, mining machinery, forklift truck, agricultural machinery, ship, petroleum machinery, construction, pump valve, mechanical and electrical, hardware tools, electric power equipment, etc.
Leesh capability
Method: Investment Casting, Lost Wax Casting, Precision Casting
| Process Description | Process Control | |||
| Mass(kgs) | General Tolerance Standard | Casting Tolerance(CT) | Surface Rougness(μm) | |
| Silicon Sol | 0.005-50 | ISO 8062 | CT4-CT6 | Ra 3.2～6.3 μm |
| Water Glass | 0.10-100 | ISO 8062 | CT6-CT8 | Ra 6.3～12.5 μm |
Material: Stainless Steel (General SUS304, SUS316, 1.4301), etc.，Stainless Iron (General 201, 420, 430), etc.，High/Middle/Low Carbon Steel (A3, Q235, 45), etc.，Alloy Steel (General 20cr, 20crmo, 20crnimo, 40cr, 40crmo, 40crnimo, 42cr, 42crmo, 42crnimo) etc.，Brass (H59, H62, H75, H80), etc.,
Red Copper, Bronze, White Copper and other materials.
The above list Is For Reference Only, If You Have Special Needs, Please Contact Customer Service Staff.
Post Casting Process: Ordinary Polishing, Mirror Polishing, Electrolytic Polishing, Brushed Finishing, Grinding, Heat Treatment, Finishing, Drilling and Tapping,Plating, etc
Surface Treatment: polishing, powder coating, zinc plating, chrome plating,heat treatment,tumbling polishing, electro-polishing
